Blockchain data is by nature, streaming event-based data. It’s a perfect fit for Reactive Streams with RxJS, and data streaming technologies like Websockets and Server Sent Events.

Let’s walk through how to build superfast dApps and offload the heavy lifting to a Nest.js backend. This Nest.js backend allows the client to be much thinner and allows the backend business logic to serve multiple clients such as web, mobile, native and various dev tools and analytics.

Using NestJS will allow us to re-use our components with NestJS built-in functionality to create a structured, modular way of exposing Websockets, REST API, Server Sent Events and GraphQL for multiple chains such as Ethereum, Solana and Bitcoin in a single service.

The approach detailed here is modular and re-usable, and we will be re-using the same components in future articles to demonstrate this technique with Solana, Bitcoin, and other chains.

Thin clients have:

• Much faster initial load times
• Drastically lower JS bundle download sizes
• Faster & more responsive UX
• Usability across even low-powered devices
• Better SEO b/c load time is a factor
• Less exposed attack surface exposed locally

⭐️ Some notes on ultra-thin clients vs full front-end frameworks:

While the ultra-thin clients techniques demonstrated in this tutorial may not be ideal for some production dApps, you should spend time considering if stuffing a bunch of business logic into an already bloated ReactJS app is really the right choice for your users.

ReactJS is a great full-featured framework for complex UIs with teams working on them but may not be the right choice for a prototype, hackathon project or early-stage project.

You can read more about the clean separation of the presentation/UI layer and business logic Martinfowler.com and here.

Every application has its own needs and tradeoffs, and we hope you learn some new techniques to apply to your dApp in this article.

Why Websockets

WebSockets reduce overhead up to ~98.8% compared to HTTP, by eliminating repeated handshakes, large headers payloads and by leveraging smaller message frames.

Vs HTTP Polling: WebSockets can handle up to ~390–400x more requests per second. Latency is reduced by up to ~1/3. Payload size can be ~500x-1000x smaller.

Websockets can be a huge advantage when it comes to time-sensitive, event-driven applications.

The haves paid for nanoseconds; the have-nots had no idea that a nanosecond had value.

- Michael Lewis(Author of Flash Boys)

Getting Started with Nest.js

NestJS is a comprehensive Node.js framework for building reliable, and super scalable server backends.

Learn more about Nest.js.

You can follow along with the following GitHub Repo.

Open this repo in a GitHub Codespace Devcontainer to follow along!

The nestjs-typeorm-full-example is also a template repo so you can make a copy by clicking the Use this template button. Otherwise, follow the NestJS Quickstart in the project README.

Integrating Ethers.js

Ethers.js is the current most widely used library for interacting with the Ethereum ecosystem.

Check out the Ethers.js Docs.

First we will review the NestJS module to encapsulate the library and handle its lifecycle and configuration.

Ethers Sdk Config

Full example: ethersSdkConfig.ts

The config file provides a strongly typed interface for configuring the module.

ethersSdkConfig.ts

export interface EthersSdkConfig {
    rpcServerUrl: string;
    network: string;
    apiKey?: string;
}

Ethers Sdk Module Definition

Full example: ethersSdk.module.ts

The module file provides the structure for configuring the module using the registerAsync() function.

This is a widespread pattern for NestJS modules.

ethersSdk.module.ts

@Module({imports: [ConfigModule]})
export class EthersSdkModule {
    static registerAsync(options: EthersSdkModuleAsyncOptions): DynamicModule {
        return {
            module: EthersSdkModule,
            imports: [ConfigModule],
            providers: [
                {
                    provide: CONFIG_OPTIONS,
                    useFactory: options.useFactory,
                    inject: [ConfigService],
                },
                EthersSdkService,
            ],
            exports: [EthersSdkService],
        };
    }
}

Ethers Sdk Service

Full example: ethers.sdk.service.ts

The service file provides an interface to a reusable singleton instance of a Provider for other classes to use.

The constructor initializes the EthersJS Provider.

ethers.sdk.service.ts constructor

export class EthersSdkService extends SdkServiceBase<EthersProvider> implements SdkService {
    // ...
    private readonly _rpcServerUrl: string;
    private network: string | ethers.Network;

    constructor(
        private _configService: ConfigService,
        @Inject(CONFIG_OPTIONS) private options: ethersSdkConfig.EthersSdkConfig,
    ) {
        super(`Ethers SDK Rpc Server is not initialized.`);
        this._rpcServerUrl = options.rpcServerUrl;
        this.network = options.network;
        this._rpcServer = new ethers.JsonRpcProvider(
            this._rpcServerUrl + options.apiKey,
        );
    }

    // ...
}

Various functions are exposed to allow other classes to access Ethers.js functionality.

ethers.sdk.service.ts function example

export class EthersSdkService extends SdkServiceBase<EthersProvider> implements SdkService {
    // ...

    getBlock(blockHashOrBlockTag: ethers.BlockTag): Promise<BlockOrNull> {
        return this._rpcServer.getBlock(blockHashOrBlockTag);
    }

    // ...
}

Lifecycle hooks manage various lifecycle events in managing the server.

ethers.sdk.service.ts lifecycle hook example

export class EthersSdkService extends SdkServiceBase<EthersProvider> implements SdkService {
    // ...
    async onModuleInit() {
        this.network = await this._rpcServer.getNetwork();
        this.connected();
        this.logger.log(
            `Ethers SDK Rpc Server Status: ${this._rpcServerStatus} - RPC Server URL: ${this._rpcServerUrl}`,
        );
    }

    // ...
}

Ethers Sdk Service Configuration

The function registerAsync() configures the dynamic EthersSdkModule asynchronously at runtime.

app.module.ts excerpt

EthersSdkModule.registerAsync({
    imports: [ConfigModule],
    useFactory: (configService: ConfigService) =>
        ({
            network: 'Mainnet',
            rpcServerUrl: configService.get<string>('ETHERS_RPC_SERVER_URL'),
            apiKey: configService.get<string>('ETHERS_RPC_API_KEY'),
        }) as EthersSdkConfig,
    inject: [ConfigService],
})

Using the EthersSdk Module

The EthersSdk module is a reusable component that can be used anywhere in your service.

Ethers Service Constructor

The EthersSdkService is injected into the EthersService as a dependency.

ethers.service.ts excerpt

@Injectable()
export class EthersService {
    // ...
    constructor(private readonly ethersSdkService: EthersSdkService) {
    }

    // ...
}

Ethers Service getFinalizedBlocksJson Function

The EthersService defines a function that invokes getFinalizedBlock() and transforms the response into a FinalizedBlock.

ethers.service.ts excerpt

export class EthersService {
    // ...
    readonly _getFinalizedBlocksJson: () => Promise<FinalizedBlock> =
        async (): Promise<FinalizedBlock> => {
            const blockOrNull = await this.ethersSdkService.getFinalizedBlock();
            if (blockOrNull === null) {
                return {} as FinalizedBlock;
            }

            return {
                blockNumber: blockOrNull.number,
                date: blockOrNull.date ?? '',
                hash: blockOrNull.hash ?? '',
            } as FinalizedBlock;
        };
    // ...
}

Ethers Service getFinalizedBlocksJson Function

This function finalizedBlocksStreamForWebsocket passes the _getFinalizedBlocksJson() arrow function to buildWsResponse() with the generic type FinalizedBlock.

The returned WsResponse<FinalizedBlock> is then wrapped into an Observable stream of data using from().

ethers.service.ts excerpt

export class EthersService {
    // ...
    finalizedBlocksStreamForWebsocket(): (
        n: number,
    ) => Observable<WsResponse<FinalizedBlock>> {
        return (n: number): Observable<WsResponse<FinalizedBlock>> =>
            from(buildWsResponse<FinalizedBlock>(n, this._getFinalizedBlocksJson));
    }

    // ...
}

Message Utilities buildWsResponse Function

The function buildWsResponse() creates a WsResponse object and sets the data field to the results of the passed in function _getFinalizedBlocksJson()

message-utils.ts excerpt

export async function buildWsResponse<DataType>(
    n: number,
    sdkFunction: () => Promise<DataType>,
): Promise<WsResponse<DataType>> {
    return {
        type: 'events',
        data: await sdkFunction(),
    } as unknown as WsResponse<DataType>;
}

Websocket Gateway Event Listener

The onEvent() function is decorated with the @SubscribeMessage('ethers-subscribe-blocks') annotation that listens for incoming websocket messages that have event: "ethers-subscribe-blocks" in the payload.

It performs the following:

• Validates that the data is the correct JSON shape matching WebSocketSubscribeDto
• Then returns a new stream of data based on the topic included in the DTO payload
• A stream of WsResponse JSON objects are emitted with the data depending on the topic

ethers.gateway.ts excerpt

@WebSocketGateway(81, {cors: {origin: '*'}})
export class EthersGateway {
    // ...
    @SubscribeMessage('ethers-subscribe-blocks')
    onEvent(
        @MessageBody(new ValidationPipe()) payload: WebSocketSubscribeDto,
    ): Observable<WsResponse<BlockNumber | FinalizedBlock | WsError>> {
        switch (payload.topic) {
            case 'block-number':
                return this.newBlocksStream();
            case 'finalized-blocks':
                return this.finalizedBlocksStream();
            default:
                return errorMsgWsResponse(payload);
        }
    }

    // ...
}

Websocket Gateway finalizedBlocksStream

The function finalizedBlocksStream() uses the RxJS function interval(5000) to create an Observable stream of data that emits every 5 seconds.

On each emission, the finalizedBlocksStreamForWebsocket() service function is called that emits a stream of finalized block data which is merged into the interval stream.

Then the stream is de-duplicated using the distinct function, which emits data with a unique block number.

ethers.gateway.ts excerpt

export class EthersGateway {
    // ...
    private finalizedBlocksStream() {
        return interval(5000)
            .pipe(mergeMap(this.ethersService.finalizedBlocksStreamForWebsocket()))
            .pipe(distinct(({data}) => data.blockNumber));
    }

    // ...
}

Front-end Client

The thin client consists of a single .html file and a .js file.

Front-end Client - HTML

The ws-finalized-blocks.html file allows a user to subscribe to a websocket stream of finalized blocks.

The dynamic elements are:

• The article element with the id messages is appended with websocket data
• The send-message-button subscribes to websocket messages
• The close-connection-button closes the websocket stream

ws-finalized-blocks.html excerpt

<div>
    <article>
        <strong>Emitted Events - Finalized Blocks</strong>
        <p>
            <ins id="connection-status"></ins>
        </p>
        <progress id="progress-bar"></progress>
        <article id="messages"></article>
    </article>
    <div role="group">
        <button id="send-message-button"
                title="Send websocket message to subscribe to Finalized Blocks">
            Subscribe to Finalized Blocks
        </button>
        <button class="secondary" id="close-connection-button"
                title="Close websocket connection">
            Close Connection
        </button>
    </div>
</div>

Front-end Client - Javascript

The wsFinalizedBlock.js defines the basic logic to:

• Establish a websocket connection
• Send and receive websocket messages
• Close the connection

A WsConnect object is instantiated passing in:

• The websocket endpoint
• The name of the event on sent websocket messages
• The function used to generate block explorer links, createLinkEth

wsFinalizedBlock.js excerpt

const websocket = new WsConnect(
    'ws://localhost:81',
    'ethers-subscribe-blocks',
    createLinkEth,
);

A click event listener is attached to the button with the id, #send-message-button. When the button is clicked, the sendMessage() function on the WsConnect object is invoked subscribing to the 'finalized-blocks' stream of data via websocket.

wsFinalizedBlock.js excerpt

document.querySelector('#send-message-button').addEventListener('click', () => {
    console.log('Sending message to subscribe to finalized blocks');
    websocket.sendMessage('finalized-blocks');
});

A click event listener is attached to the button with the id, #close-connection-button. When the button is clicked, the closeConnection() function is called.

wsFinalizedBlock.js excerpt

document
    .querySelector('#close-connection-button')
    .addEventListener('click', () => {
        console.log(
            'Closing finalized blocks websocket connection: User Requested',
        );
        websocket.closeConnection('User Requested');
    });

Front-end Client - WsConnect Class

The WsConnect abstracts away common functions used in all websocket clients.

The constructor initializes the object and creates a new WebSocket(url) using the standard The WebSocket API

wsConnect.js excerpt

export class WsConnect {
    // ...
    constructor(url, eventName, linkFunction) {
        this.url = url;
        this.socket = new WebSocket(url);
        this.eventName = eventName;
        this.linkFunction = linkFunction;
        this.setEventHandlers();
    }

    // ...
}

The setEventHandlers() parses the returned websocket messages from the backend service and formats them for display. The raw JSON data is displayed as well as a link to etherscan built using the passed in linkFunction().

export class WsConnect {
    // ...
    setEventHandlers() {
        this.socket.onmessage = (msg) => {
            const data = JSON.parse(msg.data).data;
            const message = document.createElement('div');
            message.appendChild(document.createTextNode(msg.data));
            message.appendChild(document.createElement('br'));
            const link = this.linkFunction(data);
            message.appendChild(link);
            message.appendChild(document.createElement('hr'));
            document.querySelector('#messages').appendChild(message);
        };
    }

    // ...
}

The sendMessage() function sends a websocket message to subscribe to the desired topic.

export class WsConnect {
    // ...
    sendMessage(topic) {
        this.socket.send(
            JSON.stringify({
                event: this.eventName,
                data: {
                    client: 'vanilla.js',
                    topic: topic,
                },
            }),
        );
    }

    // ...
}

The closeConnection() function closes the websocket connection.

export class WsConnect {
    // ...
    closeConnection(reason) {
        this.socket.close(1000, reason);
        document.querySelector('#connection-status').innerHTML = '';
        document.querySelector('#progress-bar').value = 0;
    }

    // ...
}

Conclusion

Thanks for reading!

We walked through a performant, reactive dApp with WebSockets, Ethers.js, RxJS, and NestJS. This approach has a clean separation the client and a robust backend service capable of handling real-time blockchain data streams.

The backend service can then be re-used for other front-end clients, such as desktop, terminal, mobile apps, analytics, and dev tooling.

Some Key Takeaways to Consider

While there is no one right answer for every application, we hope you learned some new techniques in this article.

Benefits:

• Thin Client: Reduced bundle sizes, faster load times, and better performance across devices
• Reactive Streams: Perfect fit for blockchain’s event-driven nature using RxJS Observables
• WebSocket Efficiency: Up to 98.8% overhead reduction and 390-400x more requests per second compared to HTTP polling
• Modular Design: Reusable NestJS modules that can easily extend to multiple blockchain networks

Concepts:

• Clean Separation: Business logic resides in the backend, keeping frontend focused on presentation
• Real-time Data: Efficient streaming of blockchain events with automatic deduplication
• Scalability: Single backend service can serve multiple client types (web, mobile, analytics tools)

The modular, reactive approach demonstrated here provides a clear example of a unique way of writing dApps that can scale efficiently with a snappy, responsive UX.

Thanks again for reading and be sure to post your comments below!
